Hand Clutch Kit John Deere

Description

Kit Contains:

(3) JDS1027 Clutch Disc

• 9.250″ outside diameter
• 0.372″ thick
• (3) 5/8″ diameter holes to slide over the R1869R pins
• 1-7/8″ lining width
• When assembling, the discs slide OVER the pins NOT the T-bolts.

(2) JDS1025 Clutch Disc Facing

• 9.250″ outside diameter
• 0.156″ thick
• 1-3/8″ lining width
• The side with the grooves faces the driving disc

(1) ABC187 Belt Pulley Brake Lining

• Non-asbestos lining with countersunk brass rivets

(3) JDS6864 Clutch Disc Adjusting Springs

(3) MIS1134 Clutch Adjusting Nut

• 9/16″ – 18 NF
• Grade 5
• Slotted hex nut, 9/16″

(3) JDS1626 Clutch Pressure Plate Spring (Belleville) Washer

• 0.572″ inside diameter
• 0.937″ outside diameter
• 0.035″ thick
• Spring steel

(6) Cotter Pins

• 1/8″ x 1″
